Product Description:
Connector manufacturers, professional in producing connector for
more than 15 years
We are specialized in electronic connectors, electronic wire
harnesses and hardware development, if you couldn't find the exact
items you need, please send us your drawings or pictures, we will
provide the best solution for you.
H=7.0 Right Angle 2*40 80 Pin Stacke Round Female Pin Header 2.54mm
Double Row
Product features:environmental protection and high temperature resistance plastic, high conductivity of brass conductor, durable, stable tin or gold
plating performance, oxidation resistance and external factors
interference, long service life.
Product function: It is like a bridge, connecting the blocking current on both
sides, realizing data transmission and signal interworking.
Application scope: Pin header is widely used in displays, digital
camera, MP3, MP4, PDA, computer, computer motherboard, a variety of
mobile storage disk, card reader, security products, electricity
meter, wireless telephone, mobile phone, interphone,
program-controlled switches, VCD, DVD, LCM/LED display module,
electronic toys, household appliances etc. As the most reliable
connection board to board, wire to board provides.
| Name | Round Female Pin Header Connector/PCB Connector |
| Brand Name | RealRun |
| Place Of Origin | Guangdong,China |
| Pin(outer sleeve) | Brass,machined CuZn38Pb2 |
| Clip(contact 4 finger): | Beryllium Copper,heat treated |
| Plating(outer sleeve) | Gold plated:2μm/80μ"Ni,Full gold Tin plated:2μm/80μ"Ni,5μm/200μ"Sn |
| Plating(contact) | 2μm/80μ"Ni,gold or Tin plated |
| Insulator(black) | Glass filled thermoplastic polyester UL94V-0 |
| Current rating | 3Amps/contact max. |
| Contact resistance | ≤4mΩ contact |
| Insulation resistance | ≥1000MΩ at V=100V |
| Operating Voltage | 60V AC/DC |
| Packing | Tube Packing |
| OEM/ODM | Accepted |
| Termination | Customization |
| Contact Shape | Round Pin |
| Pin Available | Customized |
Company Profile
Shenzhen RealRun Electronic Co., Ltd established in May of 2005,
specializes in operating connectors. RealRun always regards quality
as corporate life, adheres to the business philosophy of the
quality to the market, the management to benefit and the leading
innovation and brand strategy. Since the company established,we
have payed attention to the management specification and high
quality requirements, now have passed ISO9001 quality management
system certification, all products are according with the UR RoHS
and REACH the environmental protection requirements. We always
adhere to the "market-oriented, customer satisfaction" as the
tenet, and constantly strive to be outstanding enterprise.
The company is located in Shenzhen Guangming new district, with a
floorage of 1500sq.m. for plant and 100 employees, main products:
Pin header, Female header, Box header, Ejector header, IDC series,
IC socket, single and double row round hole socket, FFC/FPC
connector and SD socket, FFC cable, flat ribbon cable, RJ45 and
RJ11, etc.
The company has a skilled R&D and management team, and
first-class level of advanced production equipment and precision
testing instruments. The domestic market is main in south China,
radiation throughout the country, the international market is main
in Hong Kong, Taiwan and the global clients.
Our Service:
1. Our aim is make sourcing connector easy for you.
2. We'll reply your inquirys within 12hours,Online Inquiry is
Welcome.
3. We provide OEM,ODM service, Any of special connector requested,
We are going to make new mould for you but mould cost half for
each.
4. 20pcs free samples, For repeat order customer,We'll provide more
than 20pcs samples for prototype project if necessary.
5. Our business is not just about connector supply, it's about
delivering promises.
