SMT 2.0mm Pitch PA6T Single Row Pin Header 6pin Tin Plating

    Buy cheap SMT 2.0mm Pitch PA6T Single Row Pin Header 6pin Tin Plating from wholesalers

    Buy cheap SMT 2.0mm Pitch PA6T Single Row Pin Header 6pin Tin Plating from wholesalers
    • Buy cheap SMT 2.0mm Pitch PA6T Single Row Pin Header 6pin Tin Plating from wholesalers
    • Buy cheap SMT 2.0mm Pitch PA6T Single Row Pin Header 6pin Tin Plating from wholesalers
    • Buy cheap SMT 2.0mm Pitch PA6T Single Row Pin Header 6pin Tin Plating from wholesalers

    SMT 2.0mm Pitch PA6T Single Row Pin Header 6pin Tin Plating

    Ask Lasest Price
    Brand Name : RealRun
    Model Number : PH2.0*4.0-1*nT-6T
    Certification : ISO9001, SGS, Rohs, Reach
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union,PayPal
    Supply Ability : 100000pcs/day
    Delivery Time : 3~7workdays
    • Product Details
    • Company Profile

    SMT 2.0mm Pitch PA6T Single Row Pin Header 6pin Tin Plating


    PA6T 2.0mm 6 pin single row and plastic SMT type pin header


    Product name: 2.0mm pin header connector

    1. Features: By using environmental protection high temperature resistant fireproof rubber and plastic, strong oxidation resistance and stability.



    2. Material: it is made of brass wire, phosphorus copper wire, copper clad steel wire, pure copper wire, tin plating nickel surface after the bottom, bottom plated nickel. High strength, high hardness, strong chemical corrosion resistance.




    3. Scope of application: widely used all kinds of products in Electronic industry, such as remote control, computer, TV, digital camera, MP3, mobile phone, U disk, electronic watch motherboard, home appliances, etc. all kinds of board-to-board, board-to-line connection.


    NamePin Header Connector
    Pitch2.0mm
    Plastic Hight4.0mm
    TypeSMT Type
    Insulator ColorBlack/Grey
    Insulator FlammabilityUL 94V-0
    Current Rating2.0A
    Contact Resistance(max)30m ohm Max
    Withstanding Voltage500V AC/DC
    Insulation Resistance(min)1000M ohm Min at DC 500V
    Contact materialsGold/Tin plating
    Contact PlatedTin or gold over nickel
    Insulator materialPA6T
    Processing Temperature-40~105℃
    PackingTray Packing
    OEM/ODMAccepted
    Mounting TypeHorizontal
    TerminationCustomization
    Contact ShapeSquare Pin
    Pin Available2 Pins to 80 Pins


    How to order?

    1,please tell us what type and quantity you need;

    2,we will make a PL for you to confirm the order details ;

    3,when we confirmed everything, can arrange the payment;

    4,finally we deliver the goods within the stipulated time;


    How to contact us?

    Send your inquiry details in the below, click "chat now", communicate with our customer service staff and they will tell you the information you need.if you can't find the product in our web, you can also send an inquiry to us, even if we don't make it, we will find the same product with good quality and price for you.


    Can i get some samples?

    Yes, we can provied some samples for you and free of charge.
