    PCB Board 2.0 Mm Pitch Connector 40 Pin DIP Type Dual Plastic Straight

    Ask Lasest Price
    Brand Name : RealRun
    Model Number : BH2.0*5.6-nP 12P
    Certification : ISO9001, SGS, Rohs, Reach
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union,PayPal
    Supply Ability : 100000pcs/day
    Delivery Time : 3~7workdays
    • Product Details
    • Company Profile

    PCB Board 2.0 Mm Pitch Connector 40 Pin DIP Type Dual Plastic Straight

    PCB Board 2.0 Mm Pitch Connector 40 Pin DIP Type Dual Plastic Straight


    Products NameBox Header Connector/Wire to Board Connector
    Pitch2.0mm
    ColorBlack/Blue
    Insulator MaterialPBT+30%GF UL94V-0
    Contact MaterialBrass
    Pin Available2Pins to 100Pins
    Current Rating3.0AMP
    Contact Resistance20mΩ Max
    Withstand Voltage500V AC/DC
    Insulation Resistance1000MΩ
    Operation Temperature-40℃ to +105℃
    Contact PlatingAu Over Ni
    Mounting TypeSurface Mount/SMT
    TerminationSolder
    OrientationHorizontal
    Soldering Temperature260℃ for 10 Seconds

    Characteristics:

    1. Female pogo pin connector, male pogo pin connector,

    2. Free samples with high class precision, 0.01mm precision

    3. High recycling, Large Current ,Low MOQ, Low-Resistance

    4. Standard & Non-Standard Pogo pin connector

    5. OEM / ODM , Can be custom Designed

    6. One Row, two rows, three rows

    7. Surface Mount Soldering, Double Head, Flat Head


    Application:

    Battery connector, Electrical DC Power connector, Electronic component connector, Electronic Products connector, LED lighting charger pogo pin connector, Medical Component pogo pin connector , Mobile Phone pogo pin connector, Mount USB pogo pin connector, Proble PCB pogo pin connector, Quick Wire connector pogo pin connector, Smartphone pogo pin connector, SMT / SMD pogo pin connector, Telecom / Mobile pogo pin connector, Wearable Devices pogo pin connector, Wearable digital device pogo pin connector, Wire Adaptors pogo pin connectors, Andor TV Box pogo pin connector, Antenna Clips Battery pogo pin connector.



    PCB Board 2.0 Mm Pitch Connector 40 Pin DIP Type Dual Plastic Straight


    Shipping:

    1. We can shipping all over the world by DHL, UPS, FEdex, TNT and EMS. The packaging is very safe and strong. Please nitfy me you have any special needs
    2. It will take around 3-7 days to reach your hands.


    Product Type & condition:
    Because of the fluctuant sales situation. the stock parts are always changing and the stock list cannot be promptly updated. So please consult the stock situation when you inquire.


    Warranty & Guarantee:
    All components we sell the quality with 30 days Return policy from the day of shipment.


    100% Guarantee Qualtiy

    • Manufactured Under Strict Controls.

    • 100% Tested (Not Just Batch Tested)

    • Quality Guarantee


    Please contact us for details.
