Header Pins 2.0Mm SMT SMD Type 2*8P PA6T PA9T PBT Black Tin Plated
For Pcb
| Name | Pin Header Connector/PCB Connector |
| Pitch | 2.54mm |
| Plastic Hight | 2.5mm |
| Type | Right Type |
| Insulator Color | Black/Grey |
| Insulator Flammability | UL 94V-0 |
| Current Rating | 2A |
| Contact Resistance(max) | 30m ohm Max |
| Withstanding Voltage | 500V AC/DC |
| Insulation Resistance(min) | 1000M ohm Min at DC 500V |
| Contact materials | Gold/Tin plating |
| Contact Plated | Tin or gold over nickel |
| Insulator material | PA6T |
| Processing Temperature | -40~105℃ |
| Packing | Tray Packing |
| OEM/ODM | Accepted |
| Mounting Type | Vertical mount smt |
| Termination | Customization |
| Contact Shape | Square Pin |
| Pin Available | 2 Pins to 80 Pins |
Product Application:
Pin header is widely used in displays, digital camera, MP3, MP4,
PDA, computer, computer motherboard, a variety of mobile storage
disk, card reader, security products, electricity meter, wireless
telephone, mobile phone, interphone, program-controlled switches,
VCD, DVD, LCM/LED display module, electronic toys, household
appliances etc. As the most reliable connection plate to plate,
wire to board provides.
Category
1. According to the spacing: 0.8, 1.0, 1.27, 2.0, 2.54, 3.96,
5.08mm;
2. According to the installation mode of layout, it is mainly
divided into 180 degrees, 90 degrees, SMT(vertical mount SMT,
horizontal SMT and right angle SMT);
3. According to the number of rows, it is divided into single row,
double row, three row and four row. At present, there are only four
rows at most;
4. According to the Height: 1.0/1.5/2.5mm;
5. Number of stitches: 02 to 80;
6. Number of stitches: 02 to 80; 02 to 100;
7. Packaging: bag, roll bag, bulk, tube, CAP/Mylar + reel tape
packing;
FAQ
Q: How long will it take to receive the goods?
A: It depends on the quantity of your order, usually 3-7 workdays
if the goods are in stock.
Q: Do you check the products before shipment?
A: Yes, before shipment, we will check the products in multiple
layers to ensure that there are no quality problems, and then
package them out of the warehouse.
Q: If there is a product quality problem, what should you do?
A: This kind of situation will not happen basically. In case it
happens, we will negotiate with you about the solution and reach an
agreement.We will bear the return and exchange costs incurred by
the product quality.
Q: Where is your factory, can i visit it?
A: Yes, welcome. our company(Weizan Electronics) is in Juhui
Industrial Park, Yutang street, Tianliao village, Guangming New
District, Shenzhen, China.
