Double Row Female Header Connector 2.54mm 180 Degree PA9T Gold Flash

    Buy cheap Double Row Female Header Connector 2.54mm 180 Degree PA9T Gold Flash from wholesalers

    Buy cheap Double Row Female Header Connector 2.54mm 180 Degree PA9T Gold Flash from wholesalers
    • Buy cheap Double Row Female Header Connector 2.54mm 180 Degree PA9T Gold Flash from wholesalers
    • Buy cheap Double Row Female Header Connector 2.54mm 180 Degree PA9T Gold Flash from wholesalers
    • Buy cheap Double Row Female Header Connector 2.54mm 180 Degree PA9T Gold Flash from wholesalers
    • Buy cheap Double Row Female Header Connector 2.54mm 180 Degree PA9T Gold Flash from wholesalers

    Double Row Female Header Connector 2.54mm 180 Degree PA9T Gold Flash

    Ask Lasest Price
    Brand Name : RealRun
    Model Number : FH2.54*5.0-2*nP 12P
    Certification : ISO9001, SGS, Rohs, Reach
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union,PayPal
    Supply Ability : 100000pcs/day
    Delivery Time : 3~7workdays
    • Product Details
    • Company Profile

    Double Row Female Header Connector 2.54mm 180 Degree PA9T Gold Flash

    Double Row Female Header Connector 2.54mm 180 Degree PA9T Gold Flash


    Product Namefemale header connector
    Pitch0.8mm,1.0mm,1.27mm,2.0mm,2.54mm,3.96mm,5.08mm
    DetailDIP,SMD,90 degree,180 degree
    HousingPA6T/PA9T/LCP+30%G.F UL94V-0
    Insulator Height for Choice3.50mm ,3.60mm ,4.50mm ,5.00mm ,5.70mm ,5.90mm ,6.00mm ,6.80mm ,6.90mm ,7.10mm ,7.20mm ,7.50mm ,8.40mm ,8.50mm ,8.60mm ,11.0mm
    Pin02~80P
    Contact MaterialPhosphor Brass,Brass
    Insulator MaterialPBT,PA6T,PA9T,LCP,PA66,PA46,PPS,PA115(Halogen Free)
    Rating Current2.00AMP
    Contact Resistance30mΩ Max
    Withstanding VoltageAC 1000V/Minute
    Insulating Resistance1000MΩ Min
    Temperture Range-40°C to +105°C
    PlatingGold(Au) or Tin(Sn) plated over Nickel(Ni)
    PackagingPE Bag,Tube,Tape&Reel,Tube+CAP,Tray,Plastic Box


    Description
    1. Female header connector is a kind of connector.
    2. Its function is to act as a bridge between the blocked or isolated circuits, and to take on the task of current or signal transmission.
    3. It is used together with the pin header to form the board to board connection; or it is used together with the electron beam end to form the board to line connection; it can also be used independently for the board to board connection.

    Double Row Female Header Connector 2.54mm 180 Degree PA9T Gold Flash

    FAQ

    Q1. What is your terms of packing?
    A: Generally, we pack our goods in neutral white boxes and brown cartons. for all of the part are be use professional anti-electrostatic packaging,compressive packing.

    Q2. What is your terms of payment?
    A: T/T 100% before delivery. wester union ,Money gram ,Escrow ,for the customer who cooperate with us more than 6-12months ,we will offer limited Net payment .

    Q3. What is your terms of delivery?
    A: EXW, FOB,COC.

    Q4. How about your delivery time?
    A: Generally, it will take 3~7 days after receiving your payment. The specific delivery time depends
    on the items and the quantity of your order.

    Q5. Can you produce according to the samples?
    A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

    Q6. What is your sample policy?
    A: We can supply the sample quantity if we have ready parts in stock, but the customers have to pay
    the courier cost,for the samples cost depend on the items.

    Q7. Do you test all your goods before delivery?
    A: Yes, we have 100% test before delivery

    Q8: How do you make our business long-term and good relationship?
    A:1. We keep good quality and competitive price to ensure our customers benefit ;
    2. We respect every customer as our friend and we sincerely do business and make friends with them,
    no matter where they come from.Thanks for all of you to reading this ,we will be one of your best supplier !
