EH Series Shrouded Header Connector 2.0mm Plating Gold For PCB board

Description

1. Ejector header connector is one of many connector types.

2. It is not only a European type connector, but also a variety of connector classified according to the actual use. Because its shape is similar to horns, it is called ejector header connector. Ejector header connector is a very simple internal wiring equipment.

How to use Shrouded header connector?
Ejector header connector usually needs to pay attention to the insertion direction, perpendicular to the insertion direction and inclination.
1. Insertion direction: when the connector is fully inserted to u = 14.2, the specified contact resistance shall be ensured.
2. Perpendicular to the insertion direction: if the printed board or fixed board mounted connector is floating mounted, the design of free and fixed board mounted connector shall provide at least 1mm adjustable displacement.
3. Inclination: the design of free and fixed plate mounted connectors allows inclination error, which is ± 4 ° in longitudinal direction and ± 4 ° in transverse direction.

Category

1. According to the spacing: 1.0mm, 1.27mm, 2.0mm, 2.54mm.

2. No. of pins: 2~80 pins.

3. According to the installation mode of layout, it is mainly divided into 180 degrees, 90 degrees, SMT(vertical mount SMT, horizontal SMT and right angle SMT).

Shipping:
1. We can shipping all over the world by DHL, UPS, FEdex, TNT and EMS. The packaging is very safe and strong. Please nitfy me you have any special needs
2. It will take around 3-7 days to reach your hands.

Product Type & condition:
Because of the fluctuant sales situation. the stock parts are always changing and the stock list cannot be promptly updated. So please consult the stock situation when you inquire.

Why choose RealRun?

1. RealRun has more than 10 years experiences in the electronic connectors area.

2. The goods with good quality and service are sold to more than 70 countries.

3. More, all the goods have the relevant approvals and the service is excellent if you will consider us to be your supplier.

4. One of the biggest electronic connectors supplier in the China mainland.

Shenzhen RealRun Electronic Co., Ltd established in May of 2008, specializes in operating connectors. Main products: Pin header, Female header, Box header, Ejector header, IDC series, IC socket, single and double row round hole socket, FFC/FPC connector and SD socket, FFC cable, flat ribbon cable, RJ45 and RJ11, etc.

Products are mainly used in:instrumentation, communication, security, medical equipment, computer motherboards, program-controlled switch, digital camera, LED photoelectricity, etc.

The face of strong demand customization, our strong R&D center, mold manufacturer and processing center, which can quickly grasp customer needs, providing OEM/ODM products with the most reliable product and precise connectors for different customers.

The company is located in Shenzhen Guangming new district, with a floorage of 1500sq.m. for plant and 100 employees.The company has a skilled R&D and management team, and first-class level of advanced production equipment and precision testing instruments. The domestic market is main in south China, radiation throughout the country, the international market is main in Hong Kong, Taiwan and the global clients.

Sincerely welcome customers home and abroad to discuss cooperations! Sincerely thanks to our customers for more than 13 years of cooperation and guidance, we will be strict in management of the production of science and technology, good quality, as always, to serve you.
